Non-programmable
Standalone analog architecture without firmware or software dependencies.
BRAKE SYSTEM PLAUSIBILITY DEVICE
Engineered for
Formula Student.
Analog. Non-programmable. Designed for Formula Student combustion and combustion-hybrid vehicles in the European market.
DESIGNED AROUND THE REQUIREMENTS
Built for Formula Student combustion vehicles.
⌁
Dual-signal plausibility
Monitors brake pressure and throttle position as the key input conditions.
◷
Time-dependent logic
Implements the required plausibility persistence and reset behaviour.
⌁
Protected inputs
Designed with filtering, hysteresis and input protection for a demanding environment.
↗
Ready to integrate
PCB supplied assembled together with the connector and terminal hardware needed for installation. Current validation has been performed on a combustion vehicle.
VALIDATED ON REAL HARDWARE
Tested, measured,
not just simulated.
Functional testing was performed on the manufactured PCB using controlled sensor-signal pulses and direct output verification.
470 msMeasured minimum trigger point
10 sReset behaviour verified
BSPD SYSTEMS · ASSEMBLED PCB
THE PRODUCT
A complete PCB assembly for your vehicle.
The BSPD Systems unit is supplied as an assembled PCB, with the electronic components already fitted and soldered. The kit also includes the connector and terminal hardware required for implementation.
01Assembled PCB
Components installed and soldered.
02Connector hardware
Connector and terminal kit for implementation.
03Your own enclosure
Packaging is intentionally not included.
TECHNICAL OVERVIEW
What you need to know.
Not how it is built.
Detailed circuit architecture, component values, PCB files and manufacturing data are not publicly disclosed.
ARCHITECTUREAnalog / non-programmable
INPUTSBPS + TPS
PLAUSIBILITYBrake + throttle condition
ACTIVATION500 ms class
RESET10 s behaviour
OUTPUTSDC control
EUROPEAN FORMULA STUDENT
Developed around Formula Student Germany requirements.
Current validation covers combustion vehicles. Combustion-hybrid vehicles are grouped under the CV class in the FSG 2026 rules; electric vehicles require a different BSPD trigger condition and are therefore not covered by this product version.
EUROPE · CV / HY
REQUEST A BSPD SYSTEMS UNIT
Tell us about your vehicle.
We will review your requirements and contact you with availability, technical information and the next steps.
- Formula Student teams
- Technical questions welcome
- Pricing and availability handled directly
